New HiFi Full Range Speakers in Miniature Size!
High-quality HiFi full range speakers, 50WMAX, 8Ω (/8) or 4Ω (/4)
These full range speakers combine numerous highlights of the speaker technology on a minimum of space: a Kevlar cone of extra low weight, but nevertheless well dampened, a motor system with full air ventilation, a high-quality NEODYMIUM magnetic system with double magnet and a newly developed basket which allows mounting at a favourable price even with multiple arrangements. These small speakers of amazingly high efficiency can be used for versatile applications, ranging from small speakers for background PA applications or e.g. rear speakers in home cinema systems, applications as mid-high range speakers or full range midrange speakers in high-end HiFi speaker systems to multiple arrangements in column speakers.
Technical Specification
- Impedance (Z) : 8Ω
- Resonant frequency (fs): 105Hz
- Max. frequency range : f3-17,000Hz
- Music power : 50WMAX
- Power rating (P) : 20WRMS
- SPL (1W/1m) : 87dB
- Suspension compl. (Cms): 0.90mm/N
- Moving mass (Mms): 2.65g
- Mech. Q factor (Qms): 8.59
- Electr. Q factor (Qes): 0.49
- Total Q factor (Qts): 0.46
- Equivalent volume (Vas): 1.13 l
- DC resistance (Re): 5.7Ω
- Force factor (BxL): 4.48Tm
- Voice coil induct. (Le): 0.5mH
- Voice coil diameter: 21mm
- Voice coil former: Kapton
- Linear excursion (XMAX): ±2mm
- Eff. cone area (Sd): 30cm2
- Magnet weight : NEODYMIUM
- Weight : 150g
